Working Principle
The powder raw material and adhesive in a cylinder are fully mixed at the bottom to become a humid soft material. Then it is cut by high-speed cutter and become uniform granules .
Characteristics
◎The machine adopts horizontal cylinder structure, its structure reasonable.
◎Air lled seal shaft for to drive. When washing , it can be changed to water.
◎Fluidized Granulation, the granule is around ball shape. Its ow ability is good.
◎Compared to traditional process, 25% of adhesive can be reduced and the drying time is short.
◎The dry mixing time is 2 minutes and the granulating time is 1-4 minutes.
◎Compared to the traditional process , 4-5 times of ef ciency is raised.
◎Dry mixing ,humid mixing and granulating are nished in the same sealed container.
◎The whole operation has strict safe and protective measures.
◎Jacket type might be adopted on request.
Technical Parameter
| Type |
A |
B |
C×D |
E |
F |
| 50 |
320 |
950 |
1250×800 |
970 |
1650 |
| 150 |
420 |
1000 |
1350×800 |
1050 |
1750 |
| 200 |
500 |
1100 |
1650×940 |
1450 |
2050 |
| 250 |
500 |
1160 |
1650×940 |
1400 |
2260 |
| 300 |
550 |
1200 |
1700×1000 |
1400 |
2310 |
| 400 |
670 |
1300 |
1860×1100 |
1550 |
2410 |
| 600 |
750 |
1500 |
2000×1230 |
1750 |
2610 |
| Name |
Type |
| 50 |
150 |
200 |
250 |
300 |
400 |
600 |
| Volume L |
50 |
150 |
200 |
250 |
300 |
400 |
600 |
| output capacity kg/batch |
15 |
50 |
80 |
100 |
130 |
200 |
280 |
| admix speed r.p.m |
200/400 |
180/270 |
180/270 |
180/270 |
140/220 |
106/155 |
80/120 |
| admix power kw |
4/5.5 |
6.5/8 |
9/11 |
9/11 |
13/16 |
18.5/22 |
22/30 |
| cutting speed r.p.m |
1500/3000 |
1500/3000 |
1500/3000 |
1500/3000 |
1500/3000 |
1500/3000 |
1500/3000 |
| cutting power kw |
1.3/1.8 |
2.4/3 |
4.5/5.5 |
4.5/5.5 |
4.5/5.5 |
6.5/8 |
9/11 |
| compressed air consumption m3/min |
0.6 |
0.9 |
0.9 |
0.9 |
1.1 |
1.5 |
1.8 |
| weight kg |
500 |
800 |
1000 |
1300 |
1800 |
2200 |
2600 |
|
